ABSOLUTE MAXIMUM RATINGS

Table 4.
With
Parameter Respect To
VDDA VSSA
VDD33 VSS
VDD VSS
VDDC VSSC
VSSA VSS
VSSA VSSC
VSS VSSC
DACCLK_P, VSSC
DACCLK_N
DCI, DCO VSS
LVDS Data Inputs VSS
IOUTP, IOUTN VSSA
I120, VREF, IPTAT VSSA
IRQ, CS, SCLK, SDO, VSS
SDIO, RESET
Junction Temperature
Storage Temperature
Stresses above those listed under Absolute Maximum Ratings
may cause permanent damage to the device. This is a stress
rating only; functional operation of the device at these or any
other conditions above those indicated in the operational
section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect
device reliability.
Rating
−0.3 V to +3.6 V
−0.3 V to +3.6 V
−0.3 V to +1.98 V
−0.3 V to +1.98 V
−0.3 V to +0.3 V
−0.3 V to +0.3 V
−0.3 V to +0.3 V
−0.3 V to CVDD18 + 0.18 V
−0.3 V to DVDD33 + 0.3 V
−0.3 V to DVDD33 + 0.3 V
−1.0 V to AVDD33 + 0.3 V
−0.3 V to AVDD33 + 0.3 V
−0.3 V to DVDD33 + 0.3 V
150°C
−65°C to +150°C
Rev. A | Page 7 of 56

THERMAL RESISTANCE

θ is specified for the worst-case conditions, that is, a device
JA
soldered in a circuit board for surface-mount packages.
Table 5. Thermal Resistance
Package Type
160-Ball CSP_BGA
1
With no airflow movement.

ESD CAUTION

AD9739
θ θ Unit
JA JC
31.2 7.0 °C/W
