Settings And Operation - Hioki MEMORY HiLOGGER LR8450 Instruction Manual

1

Settings and Operation

1.1 Performing Basic Operations ..............................................p. 6
1.2 Setting Measurement Conditions .......................................p. 1 0
1.3 Configuring Input Channels ................................................p. 1 6
1.4 Configuring the Waveform Display .....................................p. 3 6
1.5 Using the Scaling Function .................................................p. 4 2
1.6 Entering Comments .............................................................p. 4 7
1.7 Configuring Channels in a List ...........................................p. 5 0
1.8 Performing Zero Adjustment ...............................................p. 5 7
1.9 Checking Input Signals (Monitor Function) .......................p. 5 8
1.10 Starting and Stopping Measurement ................................p. 5 9
1.11 Observing Waveforms ........................................................p. 6 0
1.12 Using the A/B Cursors .......................................................p. 7 5
1.13 Configuration Navigator (Quick Set) ................................p. 7 8
Unit Measure
This chapter introduces basic settings and instrument
operation.
Before starting measurement, you must set measurement
conditions such as recording interval and range. You must
also configure input channel settings such as input signal
types and ranges.
