Basic Specifications
3. Display
Sheet function
Waveform display
screen
Display format
Numerical display
format
Waveform colors
Zooming in and out on
the waveform display
Waveform scrolling
Monitor display
236
Display sheets can be switched between all channels and individual modules.
All-channel display sheet: Maximum 120 analog channels, 30 waveform calculation
channels, 8 pulse/logic channels, 8 alarm channels
Time-axis waveform Simultaneous display of gages and settings (channel
display representative settings and display settings)
Simultaneous display Instantaneous values, cursor values, or numerical calculation
of time-axis waveforms values (user-switchable)
and values
Numerical display Simultaneous display of instantaneous values and statistical
values
Alarm display Display of alarm status and alarm history
Time-axis waveform display: 1 screen
SI units, decimal, or exponent (user-selectable)
When decimal is selected, the number of decimal places to display can be set (values
will then be rounded to the set number of places).
24 colors
Horizontal axis 2 ms, 5 ms, 10 ms, 20 ms, 50 ms, 100 ms, 200 ms, 500 ms, 1 s,
2 s, 5 s, 10 s, 20 s, 30 s, 1 min., 2 min., 5 min., 10 min., 20 min.,
30 min., 1 h, 2 h, 5 h, 10 h, 12 h, 1 day/division
Vertical axis Number of divisions per screen: 10
Setting method
Select position or upper and lower limits for each channel.
(Waveform calculation channels: upper and lower limits only)
• When setting by position: Set zoom factor and zero position.
Zoom factor: 1/2×, 1×, 2×, 5×, 10×, 20×, 50×, 100×
Zero position: −50% to 150% (with a zoom factor of 1×)
• When setting by upper/lower limit: Set the upper and lower
limit.
The display can be scrolled left and right both during recording and while recording is
stopped (during waveform rendering only).
The user can check instantaneous values and waveforms without recording data to
memory (values and waveforms can be displayed while waiting for a trigger).
