1.6 Entering Comments

This section describes how to enter measurement titles, channel comments, and module identifiers.

Title comments

This section describes how to enter a string of text to serve as the measurement title. (Up to 40
single-byte characters)
See "Text entry method" (p. 8 ).
Title comments are displayed at the top of the waveform screen.
You can use title comments to identify measurement based on image data when display
screenshots are saved.
> >
1 1
1
Select [Title comment]
and press the ENTER
The text entry window will open.
See "Text entry method" (p. 8 ).
2
Enter text and press the
The entered text will be accepted.
Unit Measure
with the Left Arrow, Right
key.
ENTER key.
Channel Trigger Alarm
Arrow, Up Arrow, and Down Arrow
Calculation System

Entering Comments

1
keys
