Moving waveforms (scrolling)

This section describes how to move (scroll) the measured waveform horizontally (along the time
axis).
Since waveforms can also be moved while measurement is in progress, you can check past
waveforms during measurement.
Past
Screen
Scrolls quickly toward past data.
Scrolls toward past data.
If you wish to move to the most recent waveform
Past
During measurement, press the
selected or use the jump function to move to the end of the waveform.
See "Jump function (changing the display position)" (p. 7 4).
If you wish to move to the beginning of the waveform
Past
Screen
Use the jump function to move to the beginning of the waveform.
See "Jump function (changing the display position)" (p. 7 4).
Unit Measure
Most
recent
Scrolls toward the most recent data.
Screen
ENTER key while
Channel Trigger
Switches the
function
(waveform movement or A/B cursor
movement).
Scrolls quickly toward the most
recent data.
Most recent
[Follow] (on the bottom right of the screen) is
Most recent
Alarm Calculation System
Observing Waveforms
SCROLL/CURSOR keys
