Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 291

Text Format
*3: Outputted according to the measured data type as follows.
Data type
Analog
Pulse, waveform
calculation
Logic
Alarm
Alarm source
Event mark
*4: Varies depending on the data type
Data type
Analog, pulse,
waveform
calculation
Logic
Break in
thermocouple,
wireless
communication
error, low battery
288
Exponential notation (six significant figures)
Exponential notation (10 significant figures)
0: Low, 1: High
0: Not issued, 1: Issued
Hexadecimal notation (blank character when no alarm is issued)*
0: No mark assigned, 1 or greater: Marks assigned
Alarm onset statuses are outputted with channels assigned to each bit. (CH1
is assigned to the most significant bit [MSB].) An analog output and waveform
calculation output are represented by eight characters (32 bits); pulse output and
logic output are represented by two characters (8 bits). The letter H is added at the
end.
Example: When U1-1 issues an alarm, the alarm source output is
represented by
When a channel generates an alarm the output is represented by
otherwise, represented by
Example: When a logic channel issues an alarm, the output is represented
by .
1
An alarm source output is represented by 12 characters (11 modules and a
spare bit), in which a character (4 bits) is assigned to each module with an
alarm status incorporated.
A break in a thermocouple, wireless communication error, and low battery
state are in order beginning from the MSB (for plug-in modules, broken
thermocouple only). The letter
Example: When broken thermocouples are found in U2 and U4, the output is
represented by
Output format
Description
.
0x80000000H
. No letter is added at the end.
0
is added at the end.
H
.
0x080800000000H
4
;
1
