Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 236

-4. Interface specifications
The LAN interface and USB interface (function) cannot be used at the same time.
LAN interface LAN
Connector
Maximum cable length 100 m
LAN functionality
Wireless LAN Wireless LAN
interface
(LR8450-01 only)
Supporting mode
Connectable devices
Wireless LAN
functionality
USB interface (host) Standard compliance
Connectors
Guaranteed-operation
options
Connectable devices
IEEE 802.3 Ethernet, automatic 100Base-TX/1000Base-T
detection
Auto MDI-X, DHCP, DNS support
RJ-45
Configuring settings and controlling recording using
communications commands
Manually acquiring data using the FTP server
Acquiring files from a connected SD Memory Card or USB Drive
Automatically sending data via FTP (FTP client)
Transferring files saved on a connected SD Memory Card or
USB Drive
While measurement is in progress: Waveform files (binary, text)
After measurement has finished: Waveform files (binary, text)
Remote operation using the HTTP server
Screen display and remote operation, starting and stopping
measurement, acquiring data via FTP, setting comments
NTP client function
Time synchronization with an NTP server
Regular synchronization intervals: 1 h, 1 day
Pre-measurement synchronization function
IEEE 802.11b/g/n
Communications range: 30 m, line of sight
Encryption function: WPA-PSK/WPA2-PSK, TKIP/AES
Usable channels: 1 to 11
Auto-connect function
Wireless LAN function can be toggled on and off.
Station
Computer / tablet computer
Configuring settings and controlling recording using
communications commands
Manually acquiring data using the FTP server
Acquiring files from a connected SD Memory Card or USB Drive
Automatically sending data via FTP (FTP client)
Transferring files saved on a connected SD Memory Card or
USB Drive
While measurement is in progress: Waveform files (binary, text)
After measurement has finished:
Remote operation using the HTTP server
Screen display and remote operation, starting and stopping
measurement, acquiring data via FTP, setting comments
NTP client function
Time synchronization with an NTP server
Regular synchronization intervals: 1 h, 1 day
Pre-measurement synchronization function
USB 2.0 compliant
Series A receptacle × 2
Z4006 USB Drive (16 GB)
File system: FAT16, FAT32
Keyboard, hub (1 layer), USB Drive (1 port only)
Basic Specifications
Waveform files (binary, text)
