11.7 Text Format

Files saved in the text format consist of header and data sections.
The header includes the following information:
(1) Filename and version number
(2) Title comment
(3) Trigger time
(4) Channel number for each column*
2
(5) Measurement*
(6) Range
(7) Module identifier
(8) Comments
(9) Scaling setting
(10) Scaling conversion ratio
(11) Scaling offset
(12) Channel number*
3
(13) Data*
"File name","AUTO0001.CSV","V 1.00" ....................................................................................................(1)
"Title comment"..........................................................................................................................................(2)
"Trigger Time","19-12-26 10:15:32" ...........................................................................................................(3)
"CH","U1-1","ALM1","ALM2"," ALM-SOURCE-1-A1"," ALM-SOURCE-2-A1","W1", .................................(4)
"Mode","Voltage","Alarm","Alarm","Alarm Source","Alarm Source","Calculation", ....................................(5)
"Range","1V","","","","","", ...........................................................................................................................(6)
"UnitID","","","","","","","","" ..........................................................................................................................(7)
"Comment","","","","","","","","", ...................................................................................................................(8)
"Scaling","OFF", ........................................................................................................................................(9)
"Ratio","1.00000E+00",............................................................................................................................(10)
"Offset","0.00000E+00", .......................................................................................................................... (11)
"Time","U1-1[V]","ALM1","ALM2"," ALM-SOURCE-1-A1","ALM-SOURCE-2-A1","W1[V]","Event", ........(12)
0.000000000E+00, -3.3250000000E-02,0,0, "","", -6.6500000000E-02,0, .............................................(13)
1.000000000E-01, 2.8500000000E-02,1,0, "80000000H","", 5.7000000000E-02,0,
2.000000000E-01, 9.6000000000E-03,0,0, "","", 1.9200000000E-02,
3.000000000E-01, -2.5600000000E-02,0,0, "","", -5.1200000000E-02,0,
4.000000000E-01, 4.5600000000E-02,1,1, "80000000H ","80000000H", 9.1200000000E-02,0,
*1: Channel numbers are outputted on a data type by data type basis as follows:
Analog (Ux-xx), pulse (Py), logic (Ly), alarm (ALMy), alarm source (ALM-SOURCE
y-z), and waveform calculation (Wxx).
(x: 1 to 11, xx: 1 to 30, y: 1 to 8, z: A1 to A11/P/L/W/OTHER)
*2: Outputted according to the measurement target as follows:
Voltage (Voltage), thermocouple (Tc), resistance temperature detector (Rtd), humidity
(Humidity), resistance (Resistance), strain (Strain), count (Count), revolving speed
(Revolve), logic (Logic), alarm (Alarm), alarm source (Alarm Source), and waveform
calculation (Calculation).
1
1
and module for each row
