Assigning Event Marks during Measurement

5.1 Assigning Event Marks during Measurement

Assigning event marks to coincide with operation of the measurement target during measurement
can help facilitate later analysis.
You can then review how the waveform changed when the measurement target performed certain
operations.
When you press the
the top of the screen. You can assign up to 1000 event marks for a measurement process.
When another measurement process starts, the event numbers will be reset.
The following procedure describes how to assign event marks.
1
Press the WAVE key to display the
2
Under [Settings], select [Event].
A number of event mark settings will be displayed.
3
Press the ENTER
An event mark and number will appear at the top of the screen.
Press the ENTER
140
START key during measurement, the
[Wave+Set]
1 1
key while [Mark] is selected.
key when you wish to assign the event mark.
[] marks and numbers will appear on
screen.
2 2
3 3
