5

Marking Functionality

5.1 Assigning Event Marks during Measurement ....................p. 1 40
5.2 Assigning Event Marks with an External Signal ................p. 1 41
5.3 Assigning Event Marks When Alarms Occur .....................p. 1 42
5.4 Searching for Event Marks ..................................................p. 1 43
5.5 Reviewing Events in CSV Data............................................p. 1 44
Unit Measure
This chapter describes how to assign event marks to
waveforms during measurement.
(Up to 1000 marks can be assigned.)
You can also search for event marks and jump to their display
positions.
Event marks can be assigned by means of the following four
methods:
START
• Pressing the
• Tapping the [Mark]
measurement
• Inputting a signal to external control terminal
during measurement
• Configuring the event mark setting so that an event mark is
entered responding to alarm
Channel Trigger Alarm
key during measurement
button on the screen during
Calculation System
I/O 1 to I/O 3
5
139
