Hioki MEMORY HiLOGGER LR8450 Instruction Manual page 104

Data type Format Folder name
Setting
Binary CONFIG
conditions
DATA\(date)*
Binary
Example: 20-01-10
Waveform
1
data*
DATA\(date)*
2
Text*
Example: 20-01-10
Numerical
2
calculation Text* MEASUREMENT
results
Screen
PNG* 3 PICTURE
image data
*1: Save data in the binary format if you plan to load it with the instrument or the Logger Utility.
Some measurement setting conditions will be saved along with the waveform data. You can also
specify a range of data using the A/B cursors (partial save).
When you save waveform data after the scaling conversion in the binary format, raw data
(data prior to the scaling conversion) and scaling settings are recorded. Loading waveform
data allows waveforms after the scaling conversion to be displayed. You can review the pre-
conversion waveforms if you turn off the scaling setting.
*2: There is a limit on the number of rows that can be loaded at once when loading CSV files with
spreadsheet software.
*3: PNG format: An image format defined by the ISO/IEC 15948 international standard.
*4: Date folders ("year-month-day") will be automatically generated in the
number of files in a folder exceeds 1000, a new folder will be created.
Example: 20-01-10_1000
*5: For more information about filenames when saving data manually, see "11.6 Filenames" (p. 2 86).
*6: When a setting other than
[.TXT]. (p. 1 09)
*7: When [Individual calc]
[MEAS0001_1.CSV]
appended, as in
It is recommended to store fewer than 1000 files per folder.
You can save more than 1000 files in a single folder, but save times will increase with the file
count.
Additionally, the file screen can display a maximum of 1000 files. During automatic saving, a new
folder will be created when the number of files in a folder exceeds 1000.
Unit Measure
Filename
(Automatically
numbered from 1)
CONF0001.SET
4
AUTO0001.MEM
WAVE0001.MEM
AUTO0001.CSV
4
WAVE0001.CSV
6
*
AUTO0001.CSV
MEAS0001.CSV
7
*
3
*
[Comma] is selected under [Delimiter], the extension will be set to
is selected, the string representing a calculation number will be
and [MEAS0001_2.CSV].
