ADuC812
Revision History
Location
Data Sheet changed from REV. A to REV. B.
Entire Data Sheet has been revised . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . All
OUTLINE DIMENSIONS
Dimensions shown in inches and (mm).
52-Lead Plastic Quad Flatpack
(S-52)
0.094 (2.39)
0.557 (14.15)
0.084 (2.13)
0.537 (13.65)
0.037 (0.95)
0.026 (0.65)
52
1
PIN 1
SEATING
PLANE
TOP VIEW
(PINS DOWN)
0.012 (0.30)
13
0.006 (0.15)
14
0.008 (0.20)
0.006 (0.15)
0.025 (0.65)
0.082 (2.09)
BSC
0.078 (1.97)
SQ
40
39
0.398 (10.11)
SQ
0.390 (9.91)
27
26
0.014 (0.35)
0.010 (0.25)
