OUTLINE DIMENSIONS
0.065 (1.65)
0.049 (1.25)
0.010 (0.25)
0.004 (0.10)
COPLANARITY
0.004 (0.10)
ORDERING GUIDE
1, 2
Model
Temperature Range
AD5100YRQZ-0
−40°C to +125°C
AD5100YRQZ-1RL7
−40°C to +125°C
AD5100YRQZ-1REEL
−40°C to +125°C
EVAL-AD5100EBZ
1
Z = RoHS Compliant Part.
2
AD5100YRQZ-0 = Non-OTP programmed part, intended for evaluation purposes only.
AUTOMOTIVE PRODUCTS
The AD5100 models are available with controlled manufacturing to support the quality and reliability requirements of automotive
applications. Note that these automotive models may have specifications that differ from the commercial models; therefore, designers
should review the Specifications section of this data sheet carefully. Only the automotive grade products shown are available for use in
automotive applications. Contact your local Analog Devices account representative for specific product ordering information and to
obtain the specific Automotive Reliability reports for these models.
0.197 (5.00)
0.193 (4.90)
0.189 (4.80)
16
9
0.158 (4.01)
0.154 (3.91)
0.150 (3.81)
1
8
0.069 (1.75)
0.053 (1.35)
SEATING
PLANE
0.025 (0.64)
BSC
0.012 (0.30)
0.008 (0.20)
COMPLIANT TO JEDEC STANDARDS MO-137-AB
CONTROLLING DIMENSIONS ARE IN INCHES; MILLIMETERS DIMENSIONS
(IN PARENTHESES) ARE ROUNDED-OFF INCH EQUIVALENTS FOR
REFERENCE ONLY AND ARE NOT APPROPRIATE FOR USE IN DESIGN.
Figure 31. 16-Lead Shrink Small Outline Package [QSOP]
(RQ-16)
Dimensions shown in inches
Package Description
16-Lead QSOP
16-Lead QSOP
16-Lead QSOP
Evaluation Board
Rev. A | Page 35 of 36
0.244 (6.20)
0.236 (5.99)
0.228 (5.79)
0.010 (0.25)
0.020 (0.51)
0.006 (0.15)
0.010 (0.25)
8°
0.050 (1.27)
0°
0.016 (0.41)
Package Option
RQ-16
RQ-16
RQ-16
AD5100
0.041 (1.04)
REF
Ordering Quantity
1,000
2,500
