Javad TRIUMPH-VS Operator's Manual page 86

Specifications
Number
1
2
3
4
5
USB
The USB connector (Figure A-2) is a sealed receptacle ODU, p/n G80F1C-T05QF00-0000.
Ethernet
The Ethernet connector (Figure A-3) is a sealed receptacle ODU, p/n G80F2C-P07QC00-0000.
86
Table A-1. Power Connector Specifications
Signal Name
Power_INP
Power_INP
Power_GND
Power_GND
Figure A-2. USB connector
Table A-2. USB Connector Specifications
Number Signal Name
1 USB ID
2 USB_PWR
3 GND
4 USB D+
5 USB D-
Figure A-3. Ethernet Connector
Dir
P 10 to 30 volts DC input
P 10 to 30 volts DC input
P Ground, power return
P Ground, power return
Not used
2
3
1
4
5
Dir
I
P
-
I/O
I/O
2
7
3
1
6
4
5
Details
Details
USB ID
Bus power
Ground
Data plus
Data minus
