SPECIFICATIONS

■ Transceiver

D General
• Frequency coverage
U.S.A 144–148, 430–450*
144–148, 430–450*
Canada
Australia 144–148, 420–450*
144–146, 430–440
Korea
144–146, 430–432
Taiwan
136–173.995*
General
400–478.995*
1
* Guaranteed 440–450 MHz only, *
3
* Guaranteed 430–440 MHz only
• Mode
• No. of memory channels : 1250 (incl. 50 scan edges, 200 auto
• No. of call channels
• Usable temp. range
• Tuning steps
• Frequency stability
• Power supply
All stated specifications are subject to change without notice or obligation.
75
: (unit: MHz)
Transmit Receive
1
0.495–821.990,
851–866.990,
896–999.990
*
1
0.495–999.990
3
0.495–999.990
144–146, 430–440
144–146, 430–432
2
, 0.495–999.990
3
2
Guaranteed 144–148 MHz only
: FM, AM (Rx only), WFM (Rx only)
memory write channels)
: 2 channels
: –10°C to +60°C; +14°F to +140°F
: 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25,
30, 50, 100 and 200 kHz
: ±6 ppm
(–10°C to +60°C;+14°F to +140°F)
: Specified battery pack (3.7 V DC)
• Current drain
Tx High 144, 440 MHz Less than 1.5 A
Tx Low 144 MHz
1, 2
* *
440 MHz
1, 2
* *
Rx max. power
1, 2
*
standby
1, 2
* *
• Antenna connector
• External MIC/SP connector : 4-conductor 3.5(d) mm;
2, 3
* *
• Dimensions
(projections not included)
• Weight
(approx.)
2, 3
* *
D Receiver
• Receive system
• Intermediate frequencies : 1st
• Sensitivity
FM
(at 12 dB SINAD)
30.000–89.995 MHz
90.000–143.995 MHz
144.000–147.995 MHz
148.000–179.995 MHz
350.000–470.000 MHz
(430.000–450.000 MHz
600.000–939.990 MHz
940.000–999.990 MHz
:
(at 3.7 V DC)
0.4 A (approx.)
0.5 A (approx.)
Less than 150 mA
80 mA (approx.)
: SMA (50 Ω)
8 Ω(SP)/2 kΩ(MIC)
: 47(W)×81(H)×28(D) mm;
27 3
1 ⁄ (W)×3 ⁄ (H)×1
32 16
: 160 g; 5.64 oz
(with antenna and BP-243)
: Double-conversion superheterodyne
46.35 MHz (FM/AM)
14.85 MHz (WFM)
2nd 450 kHz
:
(except spurious points)
Less than 0.45 µV
Less than 0.2 µV
Less than 0.18 µV
Less than 0.2 µV
0.18 µV
Less than 0.18 µV)
Less than 1.4 µV
Less than 2.5 µV
1
⁄ ˝
8
3
⁄ (D) in
32
(typical)
