Icom IC-P7A Instruction Manual page 71

D D Auto repeater
U.S.A./KOREA versions only
The auto repeater function automatically turns ON or OFF the
duplex operation and tone encoder. The offset and repeater
tone is not changed by the auto repeater function. Reset
these frequencies, if necessary.
U.S.A. version:
• OFF : The auto repeater function is turned OFF.
• DUP ONLY : Activates for duplex only. (default)
• DUP TONE : Activates for duplex and tone.
WFMAM - DUP T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW
1 5 9
Duplex only
Korea version:
• OFF : Deactivates the function.
• ON : Activates duplex and tone. (default)
WFMAM - DUP
T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 1 5 9
Auto repeater OFF
WFMAM - DUP T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW
1 5 9
Duplex and tone
WFMAM - DUP
T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 1 5 9
Auto repeater ON
D D DTCS polarity
Sets DTCS polarity from "BOTH N" (TX/RX:
normal), "TN-RR" (TX: normal, RX: reverse),
"TR-RN" (TX: reverse, RX: normal) and
"BOTH R" (TX/RX: reverse).
WFMAM - DUP T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 9
1 5
TX/RX: Normal polarity
WFMAM - DUP T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 9
1 5
TX: Reverse, RX: Normal
10
SET MODE
(default: BOTH N)
WFMAM - DUP T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 9
1 5
TX: Normal, RX: Reverse
WFMAM - DUP T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 9
1 5
TX/RX: Reverse polarity
10
58
