■ Squelch level setting

The squelch circuit mutes the received audio signal depend-
ing on the signal strength. The transceiver has 9 squelch lev-
els, a continuously open setting and an automatic squelch
setting.
➥ While pushing and holding [SQL] (
to select the squelch level.
• "LEVEL 1" is loose squelch (for weak signals) and "LEVEL 9" is
tight squelch (for strong signals).
• "AUTO" indicates automatic level adjustment by a noise pulse
counting system.
• "OPEN" indicates continuously open setting.
SCAN
S.MW
SET SET
Push Push and hold
), rotate [DIAL]
•
ATT SET
[DIAL]
WFMAM - DUP
T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 1 5 9
Automatic squelch
WFMAM - DUP
T SQL DTCS ATT
VOL PRIO P SKIP
MR
LOW 1 5 9
Maximum level
Dual operation

■ Operating mode selection

Operating modes are determined by the modulation of the
radio signals. The transceiver has 3 operating modes: FM,
AM and WFM modes. The mode selection is stored indepen-
dently in each band and memory channels.
Typically, AM mode is used for the AM broadcast stations
(0.495–1.620 MHz) and air band (118–135.995 MHz), and
WFM is used for FM broadcast stations (76–107.9 MHz).
WFM mode cannot be selected below 30 MHz bands for all
versions (and above 850 MHz bands for USA version).
➥ While pushing and holding [FUNC], push [CALL]
( • ) several times to select the desired operating
MODE SCAN
mode.
SCAN
SCAN
S.MW
SET
BASIC OPERATION
WFMAM - DUP
T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 1 5 9
FM mode
- DUP
WFMAM T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW 1 5 9
AM mode
WFMAM - DUP T SQL DTCS ATT
VOL PRIO P SKIP MR
LOW
1 5 9
WFM mode
