Icom IC-P7A Instruction Manual page 68

10
SET MODE
D D Display backlighting
The transceiver has display backlighting with
a 5 sec. timer for night time operation. The
backlighting can be turned ON continuously
or turned OFF, if desired.
• AUTO : Lights when an operation is performed, goes out
after 5 sec. (default)
• ON : Lights continuously during transceiver power is
ON.
• OFF : Never lights.
WFMAM - DUP T SQL DTCS
VOL PRIO P SKIP MR
LOW
1 5 9
Auto setting
55
ATT WFMAM - DUP T SQL DTCS
VOL PRIO P SKIP MR
LOW
1 5 9
Continuously ON setting
D D Power save
The power save function reduces the current
drain to conserve battery power. This power
save function can be turned OFF, if desired.
In the default setting ("ON" selection), the power save func-
tion is activated in 1:4
nal is received for 5 sec. The ratio becomes 1:8
when no signal is received for another 60 sec.
1 sec.)
WFMAM - DUP
ATT
VOL PRIO P SKIP
LOW 1
Power save ON
(125 msec.: 500 msec.)
WFMAM - DUP
T SQL DTCS ATT
VOL PRIO P SKIP
MR
5 9 LOW 1
Power save OFF
ratio when no sig-
(125 msec.:
T SQL DTCS ATT
MR
5 9
