AM
(at 10 dB S/N)
0.495–4.995 MHz
5.000–29.995 MHz
118.000–136.995 MHz
WFM
(at 12 dB SINAD)
76.000–107.995 MHz
600–799.990 MHz
• Selectivity
:
FM, AM
More than 12 kHz/6 dB
Less than 30 kHz/60 dB
WFM
More than 150 kHz/10 dB
Less than 700 kHz/20 dB
• Spurious and image rejection ratio:
More than 40dB
• Audio output power
: More than 50 mW at 10%
distortion with an 8 Ω load
(at 3.7 V DC)
D Transmitter
• Modulation system
: Variable reactance frequency
modulation
• Output power
:
(at 3.7 V DC)
144 MHz
High 1.5 W, Low 0.1 W
440 MHz
High 1.0 W, Low 0.1 W
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions
: Less than –60 dB
Less than –50 dB
Less than 2.2 µV
Less than 1.4 µV
Less than 1.4 µV
Less than 1.8 µV
Less than 2.5 µV
(approx.)
(approx.)
(High power)
(Low power)
■ Battery pack (BP-243)
• Capacity
: 1800 mAh
• Battery voltage
: 3.7 V
• Charging temp. range
: 0°C to +40°C; +32°F to +104°F
• Usable temp. range
: –20°C to +60°C; –4°F to +140°F
• Storage temp. range
:
Within 1 month
–20°C to +50°C; –4°F to +122°F
Within 3 months
–20°C to +35°C; –4°F to +95°F
Within 1 year
–20°C to +20°C; –4°F to +68°F
• Dimensions
: 35.3(W)×11.4(H)×53.1(D) mm;
3
1
⁄
(projections not included)
• Charging period
: 3 hrs.
(approx.)
1
• Battery life*
: 20 hrs.
(approx.)
1
*
Operating periods are calculated under the following conditions;
Tx : Rx : standby =5 : 5 : 90, power save function: auto setting is activated
■ Battery charger (BC-164)
• Power supply
: 12 to 16 V DC or the specified Icom
AC adapter (BC-145LA/LE/LV)
• Charging current
: 760 mA±10%
• End voltage
: 4.2 V±0.1 V
• Charging temp. range
: +5°C to +35°C; +41°F to +95 °F
• Dimensions
: 67(W)×86.5(H)×50(D) mm;
5
2
⁄
(projections not included)
• Weight
: 95 g; 3.4 oz
(approx.)
14
SPECIFICATIONS
7
3
(W)×
⁄
(H)×2
⁄
(D) in
8
16
32
13
31
(W)×3
⁄
(H)×1
⁄
(D) in
8
32
32
14
76
