RT765E-2 SERVICE MANUAL
SECTION CONTENTS

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1

Environmental Protection . . . . . . . . . . . . . . . . . . . 9-1

Lubricants and Lubrication Intervals . . . . . . . . . . 9-1

Standard Lubricants . . . . . . . . . . . . . . . . . . . . . . . 9-1

Arctic Lubricants and Conditions . . . . . . . . . . . . . 9-3
Surface Protection for Cylinder Rods . . . . . . . . . . 9-6
Wire Rope Lubrication . . . . . . . . . . . . . . . . . . . . . . 9-6
lubrication Points . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
CraneLUBE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-7
Steering and Suspension . . . . . . . . . . . . . . . . . . . 9-8
Axles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10
Drive Train . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-12
GENERAL
Following the designated lubrication procedures is important
in ensuring maximum crane lifetime and utilization. The
procedures and lubrication charts in this section include
information on the types of lubricants used, the location of
the lubrication points, the frequency of lubrication, and other
information.
ENVIRONMENTAL PROTECTION
Dispose of waste properly! Improperly disposing of waste
can threaten the environment.
Potentially harmful waste used in Manitowoc cranes includes
- but is not limited to - oil, fuel, grease, coolant, air
conditioning refrigerant, filters, batteries, and cloths which
have come into contact with these environmentally harmful
substances.
Handle and dispose of waste according to local, state, and
federal environmental regulations.
When filling and draining crane components, observe the
following:
• Do not pour waste fluids onto the ground, down any
drain, or into any source of water.
• Always drain waste fluids into leak proof containers that
are clearly marked with what they contain.
• Always fill or add fluids with a funnel or a filling pump.
GROVE
SECTION 9
LUBRICATION
Drive Train (continued) . . . . . . . . . . . . . . . . . . . . 9-14
Turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-16
Outriggers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-18
Boom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-20
Boom (continued) . . . . . . . . . . . . . . . . . . . . . . . . 9-22
Boom (continued) . . . . . . . . . . . . . . . . . . . . . . . . 9-24
Hoist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-26
Hydraulic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-28
Carwell® Rust Inhibitor. . . . . . . . . . . . . . . . . . . . . 9-31
Protecting Cranes From Rusting . . . . . . . . . . . . . 9-31
Cleaning Procedures . . . . . . . . . . . . . . . . . . . . . . 9-31
Inspection and Repair . . . . . . . . . . . . . . . . . . . . . 9-32
Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-32
Areas of Application. . . . . . . . . . . . . . . . . . . . . . . 9-32
• Immediately clean up any spills.
LUBRICANTS AND LUBRICATION
INTERVALS
The service intervals specified are for normal operation
where moderate temperature, humidity, and atmospheric
conditions prevail. In areas of extreme conditions, the
service periods and lubrication specifications should be
altered to meet existing conditions.
NOTE: All fluids and lubricants may be purchased by
contacting an authorized Manitowoc distributor or
Manitowoc Crane Care Parts Department.
Chassis grease lubricants must not be applied with air
pressure devices as this lubricant is used on sealed
fittings.
The multipurpose grease applied during manufacturing is
of a lithium base. Use of a noncompatible grease could
result in damage to equipment.
Standard Lubricants
Standard lubricants are used on all Manitowoc cranes unless
the crane is ordered with a cold weather package. These
Published 9-04-2014, Control # 422-08
LUBRICATION
CAUTION
Possible Equipment Damage!
9
9-1
