SWING SYSTEM
Symptom
2.
Boom swing
operation erratic in
one direction only.
3.
Boom will not swing
in either direction.
4.
Swing operation
slow in either
direction.
6-4
Probable Cause
a.
Crane not level.
b. Turntable bearing binding due to
continuous limited swing. (Example:
concrete pourer.)
c.
Restricted hose or fitting.
d. Damaged swing directional control
valve.
e.
Damaged swing pinion.
f.
Damaged turntable bearing.
a.
Damaged relief valve.
b. Damaged swing motor.
c.
Swing brake not releasing properly.
d. Damaged hydraulic remote control
valve.
e.
Internal damage to swing box.
f.
Worn or damaged hydraulic pump.
g. Damaged swing directional control
valve.
h. Damaged swing pinion.
i.
Damaged turntable bearing.
j.
Excessive overload.
a.
Damaged relief valve.
b. Improperly adjusted swing brake.
c.
Damaged hydraulic remote control
valve.
d. Improperly lubricated swing bearing.
e.
Improper size hose and/or fittings
installed.
f.
Clogged or restricted hydraulic hoses
or fittings.
g. Worn
or
damaged
bearings
h. Worn or damaged swing motor.
i.
Worn or damaged hydraulic pump.
j.
Crane not level.
k.
Damaged swing directional control
valve.
Published 9-04-2014, Control # 422-08
RT765E-2 SERVICE MANUAL
a.
Level crane using outriggers.
b. Rotate machine 360 degrees in both
directions several times and lubricate
bearing.
c.
Replace hose or fitting.
d. Replace
valve.
e.
Replace pinion.
f.
Replace turntable bearing.
a.
Remove, clean, and repair or replace
relief valve.
b. Repair or replace swing motor.
c.
Repair as necessary.
d. Replace
valve.
e.
Remove swing box and repair.
f.
Replace pump section.
g. Replace
valve.
h. Replace pinion.
i.
Replace turntable bearing.
j.
Reduce load. Refer to load capacity
chart.
a.
Adjust, repair or replace valve.
b. Readjust.
c.
Replace
valve.
d. Lubricate bearing per
recommendations. Refer to
Lubrication, page 9-1.
e.
Replace hose or fittings. Refer to the
Manitowoc Crane Care Parts Manual.
f.
Clean or replace damaged parts.
output
shaft
g. Replace bearings.
h. Repair or replace motor.
i.
Repair or replace pump.
j.
Level crane.
k.
Replace
valve.
Solution
swing
directional
control
hydraulic
remote
control
swing
directional
control
hydraulic
remote
control
swing
directional
control
