RT765E-2 SERVICE MANUAL
SYMPTOM
3.
Telescope
cylinder will not
extend.
4.
Telescope
cylinder will not
retract.
5.
Inner mid will not
extend.
6.
Inner mid will not
retract.
7.
Outer mid will
not extend.
8.
Inner mid
retracts before
outer mid.
9.
Outer mid
extends only a
short distance
then stops.
GROVE
PROBABLE CAUSE
a.
Low hydraulic oil level.
b. Relief valve malfunctioning.
c.
Excessive load.
d. Clogged hose and fittings.
e.
Broken valve spool.
f.
Damaged piston seals.
g. Damaged piston(s).
h. Bent boom section(s).
i.
Broken hydraulic pump coupling.
j.
Worn or damaged hydraulic pump
section.
a.
Low hydraulic oil level.
b. Relief valve damaged.
c.
Excessive load.
d. Inoperative check valve.
e.
Clogged hose and fittings.
f.
Broken valve spool.
g. Broken piston(s).
h. Damaged piston seals.
i.
Bent boom section(s).
j.
Broken hydraulic pump coupling.
k.
Worn or damaged hydraulic pump.
l.
Broken hydraulic pump shaft.
a.
Right side check valve blocked.
a.
Right side check valve closed.
a.
Left side check valve is closed.
a.
Right side check valve is open or
hosed backwards.
a.
Left check valve is open or hosed
backwards.
Published 9-04-2014, Control # 422-08
SOLUTION
a.
Check system for leaks. Make repairs as
needed. Fill reservoir.
b. Repair or replace relief valve.
c.
Reduce load.
d. Replace hose or fittings. (Refer to
Manitowoc Crane Care Parts Manual).
e.
Replace valve.
f.
Replace all cylinder seals.
g. Replace piston(s) and all cylinder seals.
h. Replace damaged boom section(s).
i.
Replace broken hydraulic pump coupling.
j.
Repair or replace pump section.
a.
Check system for leaks. Make repairs as
needed. Fill reservoir.
b. Repair or replace relief valve.
c.
Reduce load. (Refer to load chart).
d. Replace check valve.
e.
Replace hose or fittings. (Refer to
Manitowoc Crane Care Parts Manual).
f.
Replace valve section.
g. Replace piston(s) and all cylinder seals.
h. Replace all cylinder seals.
i.
Replace damaged boom section(s).
j.
Replace broken hydraulic pump coupling.
k.
Repair or replace pump.
l.
Replace pump shaft.
a.
Readjust, repair, or replace valve.
a.
Readjust valve.
a.
Readjust valve.
a.
Install hoses properly.
a.
Install hoses properly.
BOOM
4
4-19
