RT765E-2 SERVICE MANUAL
shaft with a plate and the capscrews and washers on
each side of the cylinder mount.
8. Turn the lower telescope cylinder rod so the trunnion is
vertical.
9. At the rear of the fly section, install the upper wear pad
grease line, connector and grease fitting on each side.
NOTE: The grease lines are designed to be used only on
one side or the other (i.e. RH or LH).
10. Install the bottom rear wear pad on the fly section with
two flat headed screws.
11. Position the guide block on the bracket at the bottom
front of the fly section. Secure with the capscrews and
washers. Do not tighten capscrews at this time.
12. Route the two retract cables (threaded ends) through
the fly section to the front. Insert the threaded ends
through the holes on the front of the fly section and
install a washer and nuts on each cable end.
WARNING
Ensure the telescope cylinders are securely blocked and
some means used to hold them together to prevent any
accidental movement. Severe injury can occur if the
cylinders drop.
13. Using an adequate lifting device, position the upper
telescope cylinder onto the lower telescope cylinder.
14. Install two wear pads in the upper telescope cylinder
support using two flat headed screws each.
15. Position the cylinder support over the upper telescope
cylinder and secure to the lower telescope cylinder
mount with the capscrews and washers.
16. Position the sheave end of the telescope cylinder
assembly at the rear of the fly section.
17. Lay the retract cable sheave mounts out behind the fly
section as they will be installed in the outer mid. Route
the lug end of the retract cables through the sheave
mounts (top to bottom) so the lug end will come off the
bottom of the sheave. Place the retract sheave, with one
thrust washer on each side, in the mount and secure
with the shaft. Secure each shaft with two bolts and
hardened washers. Install grease fitting in each shaft
and apply grease.
18. Install the lug end of each retract cable in the slots on
each side of the lower telescope cylinder mount.
19. Slide telescope cylinder assembly into the rear of the fly
section until foot support clears the gussets at the rear of
the fly section. Lowering the rear of the fly and raising
GROVE
the rod end of the cylinders will aid in sliding these
together.
20. Place the four extend cable lug ends in the slots at the
top of the fly section and secure them with the keeper
plate, capscrews, and washers.
21. Install a wear pad on the two upper telescope cylinder
wear pad holders using two flat headed screws.
22. Position the wear pad holders on each side of the upper
telescope cylinder support foot and secure each with the
capscrews and washers.
23. Slide the telescope cylinder assembly all the way in.
Place blocking under the rear of the telescope cylinders
to aid in assembly.
24. Place the mounting plates on the upper telescope
cylinder barrel mounting lugs.
25. Using tape or ty-wraps, fasten the extend cable ends to
the telescope cylinder to aid in assembly.
26. Place the retract cable sheave mounts in the rear of the
fly section to aid in assembly.
27. At the rear of the outer mid section, install the upper
wear pad grease line, connector and grease fitting on
each side.
NOTE:
28. Install the bottom rear wear pad on the outer mid section
with the capscrews and washers.
29. Position the front end of the outer mid at the rear of the
fly/telescope cylinder assembly.
30. Slide the fly/telescope cylinder assembly into the outer
mid section installing top rear wear pads in pockets of fly
section (cutout should align with grease line). Stop and
install rear side wear pads and shims on fly section with
two flat headed screws each.
NOTE:
31. Continue to slide together being careful not to damage
cables.
32. Lift up on the front of the fly and install the bottom and
side front wear pads in the outer mid. Install shims as
necessary.
33. Position the guide block on the bracket at the bottom
front of the outer mid section. Secure with the capscrews
and washers. Do not tighten bolts at this time.
34. Install outer mid front top wear pads and shims as noted
during disassembly. Secure with the capscrews and
washers each.
Published 9-04-2014, Control # 422-08
The grease lines are designed to be used only on
one side or the other (i.e. RH or LH).
Use shims as necessary to adjust wear pad so it is
within 0.078 in (2 mm) of the outer mid section side
plate. Use equal number of shims on each side.
BOOM
4
4-11
