Manitowoc Grove RT765E-2 Service And Maintenance Manual page 252

POWER TRAIN
SYMPTOM
4. Noisy converter.
5. Lack of power.
Removal
1. Extend and set the outriggers just enough to take up the
slack in the outrigger pads. Chock the wheels.
2. Position the boom over the side and stop the engine.
3. Remove the engine and transmission/torque converter
from the crane as an assembly. Refer to Engine
Removal, page 7-2.
4. Remove the two-section and single section hydraulic
pumps from the transmission/torque converter. Cover all
openings. Refer to in Hydraulic Pumps, page 2-17 for
removal of the pump.
NOTE: The transmission/torque
approximately 966 lb (438 kg) dry.
5. Attach an adequate lifting device to the transmission/
torque converter and take up any slack.
6. Remove the capscrews and hardened flat washers
securing the drive plate assembly to the flywheel.
7. Remove the nuts
transmission/torque converter housing to the engine
flywheel housing.
Installation
NOTE: The transmission/torque
weighs approximately 966 lb (438 kg) dry.
1. If a new transmission/torque converter is to be installed,
remove all fittings and brackets from the old one and
i n s ta l l t h e m i n t h e s a m e l o c a t i o n s o n t h e n e w
transmission/torque converter.
2. Install the two-section and single section hydraulic
pumps on the transmission/torque converter. Refer to
Hydraulic Pumps, page 2-17 for installation of the
hydraulic pump.
3. Position the transmission/torque converter to the engine
with the lifting device.
4. Remove all burrs from the flywheel mounting face and
nose pilot bore. Clean the drive plate surface with
solvent.
NOTE: Refer to Figure 7-12.
7-26
PROBABLE CAUSE
a. Worn oil pump.
b. Worn or damaged bearings.
a. Low engine RPM at converter
stall.
b. See "Overheating" and make
same checks.
converter weighs
and washers securing
converter assembly
Published 9-04-2014, Control # 422-08
5. Check the engine flywheel and housing for conformance
to standard S.A.E. No. 3/S.A.E. J-927 tolerance
specifications for bore size, pilot bore runout and
mounting face flatness. Measure and record engine
crankshaft end play.
6. Install the 12 studs in the engine flywheel housing.
Rotate the engine flywheel to align a drive plate
mounting screw hole with the flywheel housing front
access hole.
7. Install a 4.00 in (101.6 mm) long drive plate locating stud
0.375-24 fine thread in a drive plate nut.
8. Rotate the transmission/torque converter to align the
locating stud in the drive plate with the flywheel drive
plate mounting screw hole positioned in step 6. Locate
the transmission on the flywheel housing, aligning the
drive plate to the flywheel and the transmission on the
flywheel housing
transmission to flywheel housing nuts and washers.
Tighten the nuts to 30 lb-ft (41 Nm).
9. Remove the drive plate locating stud. Install one drive
the
plate attaching capscrew and lockwasher. Snug the
capscrew but do not tighten.
NOTE: Some engine flywheel housings have a hole
located on the flywheel housing circumference in
line with the drive plate screw access hole. A
screwdriver or pry bar used to hold the drive plate
against the flywheel will facilitate installation of the
drive plate capscrews.
10. Rotate the engine flywheel and install the remaining
seven flywheel to drive plate attaching capscrews and
hardened flat washers. Snug the capscrews but do not
tighten. After all eight capscrews and hardened flat
washers have been installed, torque the capscrews to
28 lb-ft (38 Nm). This will require torquing each
capscrew, then rotating the engine flywheel until all
capscrews have been torqued.
11. Measure the engine crankshaft end play after the
transmission/torque converter has been completely
installed on the engine flywheel. This value must be
within 0.001 in (0.025 mm) of the end play recorded in
step 5.
RT765E-2 SERVICE MANUAL
REMEDY
a. Replace pump.
b. A complete disassembly will be
necessary to determine what
bearing is faulty.
a. Tune engine and check
governor.
b. Make corrections as explained
in "Overheating."
mounting studs. Install the
