RT765E-2 SERVICE MANUAL
7.
Using a grease gun, apply grease to the fittings on each
side plate bushing.
8.
Adjust the roller as outlined in steps 9 and 10.
9.
With one layer of cable on the hoist drum, adjust the
bolts on the front of each side plate (that push against
each arm) so the roller applies pressure on the layer of
cable, and does not interfere with filler/riser protrusions
on the hoist drum flanges. Tighten jam nuts to secure
setting.
10. With a full drum of cable, the adjusting spring length
from eye to eye should not exceed 10.12 in (25.7 cm).
Adjust rods as necessary and tighten jam nuts to secure
this setting.
GROVE
Complete Assembly
Removal
1.
Remove all tension from the springs on each side by
loosening the nuts and jam nuts.
2.
Support the weight of the assembly and remove the two
bolts and washers securing each side plate to the hoist.
Remove the idler drum and cable follower assembly
from the hoist.
3.
If necessary to completely disassemble or remove any
part of the assembly, refer to the applicable paragraphs
in this sub-section.
Installation
1.
Position the idler drum and cable roller assembly on the
hoist and secure each side plate to the hoist with two
bolts and washers.
2.
Adjust the tension on the cable follower. Refer to
instructions in Cable Follower, page 5-11.
Published 9-04-2014, Control # 422-08
HOIST AND COUNTERWEIGHT
5
5-13
