RT765E-2 SERVICE MANUAL
UNDERCARRIAGE
Rear Outriggers Shown
FIGURE 8-30
0.06 in (1.5 mm) Gap
1
1
1
8
6065
2
2
0.06 in (1.5 mm) Gap
FIGURE 8-31
Item
Description
Item
Description
1
Side Wear Pads and Setscrews
2
Bottom Wear Pads and Setscrews
GROVE
Published 9-04-2014, Control # 422-08
8-33
