Elephant Robotics myCobot Pro 600 User Manual page 59

to manage files. Users can manage program files here, and can copy them to the
U disk, or from the U disk to the system memory. If the user wants to go back to
the initial page during the programming process, click "Back".
After entering the program editing page, users can save, create and save files.
Users can also edit programs in this interface.
At the same time, users are allowed to teach points, create new variables,
view IO, view logs, set important parameters, and add functional instructions,
debugging programs and so on.
①- Function bar
The program editing page is divided into four parts:
1，Function bar
As shown in Figure 2-6, the function bar has seven sub-options, which are
divided into two categories, one is the program editing toolbar, and the other is
②
②- Program
Display Window
Figure 2- 5 Program Editing Interface
③- Functional
Editing Window
59
①
③
④
④- Program
Running Control Bar
