Elephant Robotics myCobot Pro 600 User Manual page 58

4) The most important thing is that the running program window is the channel
for the user to load and run the program that has been debugged.
5.1.2.4 Edit Program
As shown in Figure 2-4, if the user selects "Write Program" in the main
menu, two options will appear in the right window. The first is to create a program
(optional blank or template) and the second is to load the program.
①-Blank program
The user selects one as needed and then enters the program editing page as
shown in Figure 2-5.
When first entering the program edit page, the user sees the initial page as
shown in figure 2-5. In this page, common tools, initialization group and file
management functions are provided. The role of the initialization group is to
make it easy for the user to set the program content to run at the beginning of the
program and run only once. For example, set the initial point, Io State, and so on
before the robot starts formal work. File management provides users with a way
②-Pick and place
Figure 2- 4 Program Editing Window Options
①
③
③-Load program
58
