Core peripherals
4.5

SysTick timer (STK)

The processor has a 24-bit system timer, SysTick, that counts down from the reload value to
zero, reloads (wraps to) the value in the STK_LOAD register on the next clock edge, then
counts down on subsequent clocks.
When the processor is halted for debugging the counter does not decrement.
Address
Name
0xE000E010 STK_CTRL RW
0xE000E014 STK_LOAD RW
0xE000E018 STK_VAL
0xE000E01C STK_CALIB RO
246/262

Table 54. System timer registers summary

Required
Type
Reset value
privilege
Privileged
0x00000000
Privileged
Unknown
RW
Privileged
Unknown
Privileged
0xC0000000
PM0214 Rev 9
Description
SysTick control and status register (STK_CTRL)
on page 247
SysTick reload value register (STK_LOAD) on
page 248
SysTick current value register (STK_VAL) on
page 249
SysTick calibration value register (STK_CALIB)
on page 250
PM0214
