PM0214
3.5

General data processing instructions

Table 28
Mnemonic
ADC Add with carry
ADD Add
ADDW Add
AND Logical AND
ASR Arithmetic Shift Right
BIC Bit Clear
CLZ Count leading zeros
CMN Compare Negative
CMP Compare
EOR Exclusive OR
LSL Logical Shift Left
LSR Logical Shift Right
MOV Move
MOVT Move Top
MOVW Move 16-bit constant
MVN Move NOT
ORN Logical OR NOT
ORR Logical OR
RBIT Reverse Bits
REV Reverse byte order in a word
REV16 Reverse byte order in each halfword
REVSH Reverse byte order in bottom halfword and sign extend
ROR Rotate Right
RRX Rotate Right with Extend
RSB Reverse Subtract
SADD16 Signed Add 16
SADD8 Signed Add 8
SASX Signed Add and Subtract with Exchange
SSAX Signed Subtract and Add with Exchange
SBC Subtract with Carry
SHADD16 Signed Halving Add 16
SHADD8 Signed Halving Add 8
shows the data processing instructions.

Table 28. Data processing instructions

Brief description
The STM32 Cortex-M4 instruction set
ADD, ADC, SUB, SBC, and RSB on page 83
ADD, ADC, SUB, SBC, and RSB on page 83
ADD, ADC, SUB, SBC, and RSB on page 83
AND, ORR, EOR, BIC, and ORN on page 85
ASR, LSL, LSR, ROR, and RRX on page 86
AND, ORR, EOR, BIC, and ORN on page 85
CLZ on page 87
CMP and CMN on page 88
CMP and CMN on page 88
AND, ORR, EOR, BIC, and ORN on page 85
ASR, LSL, LSR, ROR, and RRX on page 86
ASR, LSL, LSR, ROR, and RRX on page 86
MOV and MVN on page 89
MOVT on page 91
MOV and MVN on page 89
MOV and MVN on page 89
AND, ORR, EOR, BIC, and ORN on page 85
AND, ORR, EOR, BIC, and ORN on page 85
REV, REV16, REVSH, and RBIT on page 92
REV, REV16, REVSH, and RBIT on page 92
REV, REV16, REVSH, and RBIT on page 92
REV, REV16, REVSH, and RBIT on page 92
ASR, LSL, LSR, ROR, and RRX on page 86
ASR, LSL, LSR, ROR, and RRX on page 86
ADD, ADC, SUB, SBC, and RSB on page 83
SADD16 and SADD8 on page 93
SADD16 and SADD8 on page 93
SASX and SSAX on page 98
SASX and SSAX on page 98
ADD, ADC, SUB, SBC, and RSB on page 83
SHADD16 and SHADD8 on page 94
SHADD16 and SHADD8 on page 94
PM0214 Rev 9
See
81/262
