AN4594
Application note
Getting started with the STM32 Nucleo and the sensor expansion
board X-NUCLEO-IKS01A1
Introduction
This document describes how to develop a sensor-based application using the STM32
Nucleo platform and the X-NUCLEO-IKS01A1 sensor expansion board, in the STM32Cube
software environment. The sensor expansion board is a multi-sensor board with
temperature, humidity, pressure and motion MEMS measuring sensors.
November 2014
DocID026958 Rev 1
1/16
www.st.com
16
Advertisement
Table of Contents
Related Manuals for ST STM32 Nucleo
Summary of Contents for ST STM32 Nucleo
- Page 1 AN4594 Application note Getting started with the STM32 Nucleo and the sensor expansion board X-NUCLEO-IKS01A1 Introduction This document describes how to develop a sensor-based application using the STM32 Nucleo platform and the X-NUCLEO-IKS01A1 sensor expansion board, in the STM32Cube software environment. The sensor expansion board is a multi-sensor board with temperature, humidity, pressure and motion MEMS measuring sensors.
-
Page 2: Table Of Contents
2.2.2 Firmware for STM32 Nucleo with X-NUCLEO-IKS01A1 expansion board ........... . 6 Hardware and software setup . -
Page 3: Acronyms And Abbreviations
AN4594 Acronyms and abbreviations Acronyms and abbreviations Table 1. Acronyms and abbreviations Acronym Description Board support package Graphical user interface Hardware abstraction layer Inter integrated circuit Integrated development environment Light emitting diode DocID026958 Rev 1 3/16... -
Page 4: Getting Started
It provides an affordable and flexible way for users to try new ideas and build prototypes with any STM32 microcontroller lines. The Arduino™ connectivity support and ST Morpho headers make it easy to expand the functionality of the Nucleo open development platform with a wide range of specialized expansion boards to choose from. -
Page 5: Software Description
AN4594 Getting started Figure 2. X-NUCLEO-IKS01A1 sensor expansion board Figure 3. Sensor expansion board connected to STM32 Nucleo board The X-CUBE-MEMS1 firmware and related documentation is available on st.com at http://www.st.com/x-nucleo. Software description The following software components are required to set up a suitable development environment for creating applications based on the sensor expansion board: •... -
Page 6: Stm32Cube
X-CUBE-MEMS1 is a package that contains firmware with the STM32 Cube framework that is compatible with the STM32 Nucleo and the X-NUCLEO-IKS01A1 boards. It has sample applications that can be used to obtain data from the sensors on the expansion board. The same sample applications are referenced in further sections of this document. -
Page 7: System Setup Guide
System setup guide This section describes how to setup different hardware components before writing and executing an application on the STM32 Nucleo board with the sensor expansion board. Sensors_Datalog GUI setup The Sensors_Datalog GUI included in the software package is a graphical user interface that can be used to interact and obtain data from the sensors on the sensor expansion board. -
Page 8: Software Overview
(MCU). This structure improves the library code reusability and facilitates portability to other devices. For detailed information regarding the STM32Cube HAL drivers API, please refer to the document “Description of STM32F4xx HAL drivers”, User manual UM1749, available from st.com at http://www.st.com/st-web- ui/static/active/en/resource/technical/document/user_manual/DM00113898.pdf. 8/16 DocID026958 Rev 1... -
Page 9: Board Support Package (Bsp)
AN4594 Software overview Board support package (BSP) The board software package (BSP) includes support for the peripherals on the STM32 Nucleo board with a limited set of APIs that provides a programming interface for certain board-specific peripherals such as the LED, the user button, etc., and also facilitates identifying the specific board version. -
Page 10: Guide For Writing Applications
4.1.1 Initialization Every application must first execute the following basic initialization steps in order to configure and set up the STM32 Nucleo with the sensor expansion board hardware and the software stack for correct operation. Initializing STM32Cube HAL The STM32Cube HAL library must be initialized so that the necessary hardware components are correctly configured. -
Page 11: Application Description
AN4594 Guide for writing applications Reading data from sensor expansion board The BSP provides the API and the functionality for taking the data from sensors. Once the sensors are initialized we can get data from them using these functions: • BSP_HUM_TEMP_GetTemperature(float * Temp) This API gives the access to temperature sensor data. -
Page 12: Using The Sensors_Datalog Application
Using the Sensors_Datalog application This section describes the Sensors_Datalog utility. The user must first ensure that the necessary drivers described in previous sections are installed and the STM32 Nucleo with the expansion board is connected to a PC. Please follow the sequence below: Check the windows “device manager”... - Page 13 AN4594 Using the Sensors_Datalog application Figure 7. Sampling interval selection You can save the log to a file that you can find in a folder called “SensorsDataLog”; or you can clear the log by pressing the “ClearLog” button. Check the “Plot” CheckBox to see a data log for the sensors that you have selected. Figure 8.
- Page 14 Using the Sensors_Datalog application AN4594 Figure 9. Sensor data visualization in the Sensors_Datalog utility window 14/16 DocID026958 Rev 1...
-
Page 15: Revision History
AN4594 Revision history Revision history Table 2. Document revision history Date Revision Changes 19-Nov-2014 Initial release. DocID026958 Rev 1 15/16... - Page 16 ST products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on ST products before placing orders. ST products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgement.
