7.6 Set Trigger Source

Apart from the internal trigger mode, you need to set the trigger source for line trigger or frame
trigger if their trigger signals come from external signals. Six types of trigger sources are available,
including software trigger, hardware trigger, shaft encoder control, frequency converter control,
frame grabber trigger control, and free trigger.
Trigger Supported
Source Trigger Mode
Software Frame trigger
Trigger
Hardware Frame trigger or
Trigger line trigger
Shaft Encoder Line trigger
Control
Frequency Frame trigger or
Converter line trigger
Control
Frame Frame trigger or
Grabber line trigger
Trigger
Control
Camera Link Line Scan Camera
Parameter Value
Table 7-2 External Trigger Mode Principle and Parameter
Parameter
Acquisition
Control >
Trigger Source
Acquisition
Control >
Trigger Source
Acquisition
Control >
Trigger Source
Acquisition
Control >
Trigger Source
Acquisition
Control >
Trigger Source
User Manual
·
Parameter Principle
Value
Software The software sends trigger signal to
the camera via Camera Link
interface to acquire images.
Specific Line External device connects camera via
camera I/O interface. External
device sends trigger signal to
camera to acquire images.
Encoder This trigger source uses shaft
Module Out encoder module to receive signal A
and signal B with phase difference.
After internal computing of the
module, the outputted signal can be
used as camera's trigger signal.
Frequency This trigger source allows different
Converter frequency between trigger camera
signal and required input signal.
CC1/CC2/CC3/C Frame grabber triggers camera to
C4 acquire images by sending signal via
Camera Link cable.
21
Principle
the internal configured value.
Only after the frame trigger
signal arrives, the line trigger
signal will work.
