Camera Link Line Scan Camera User Manual
·
Figure 10-35 Set Parallax Direction and Pixel Shift

10.21 Set Color Abnormal Correction

The color abnormal correction function may differ by camera models.
The color abnormal correction (CAC) is used to eliminate abnormal color on image edges.
Steps:
1. Click Shading Correction, and find CAC Edge Threshold.
2. Enter CAC Edge Threshold according to actual demands. The range of CAC Edge Threshold is
between 0 and 2040.
3. Enable CAC Enable.
Figure 10-36 Set Color Abnormal Correction
The CAC will be performed only when the edge strength is higher than the configured threshold.
76
