3. Connect the camera to a suitable power adapter via the power and I/O cable.
 The camera interface for connecting Camera Link cable is SDR interface, and you need to select
applicable Camera Link cable according to camera interface and frame grabber model you use,
and connect camera's Camera Link interfaces to respective interfaces of the frame grabber.
 The camera has 2 Camera Link interfaces, and it can transmit data via 1 or 2 Camera Link
interface(s). If you need to use 1 interface, the corresponding interface number is CL1, and the
Base configuration mode is available. If 2 interfaces are required, the corresponding interface
number is CL1 and CL2, and the configuration mode of Base, Medium, Full or 80-bit is
available.
 The configuration mode is decided by the camera, frame grabber, and used Camera Link
interface amount.
