HikRobot MV-CL042-91CM User Manual page 63

The wiring of using the frame grabber to have a frame trigger and using 12 V or 24 V encoder
differential signal to have a line trigger is shown below.
With different input voltages (VCCC) of the encoder signal, the respective resistance values are also
different.
VCC
12 V
24 V
The wiring of using the frame grabber to have a frame trigger and using 12 V or 24 V encoder
differential signal as the single-ended signal to have a line trigger is shown below.
Camera Link Line Scan Camera
PWR
Camera Power
Differential Input 0 Positive
Differential Input 0 Negative
Differential Input 1 Positive
Differential Input 1 Negative
Camera Power Ground
Figure 9-17 Line + Frame Trigger Wiring (I)
Differential Input 0 Positive
Differential Input 0 Negative
Camera Power
Camera Power Ground
Differential Input 1 Negative
Differential Input 1 Positive
Figure 9-18 Line + Frame Trigger Wiring (II)
Table 9-3 Relation between Voltage and Resistance
R1 R2
6.2 KΩ 4.7 KΩ
18 KΩ 4.7 KΩ
User Manual
·
5 V
GND
PWR
GND
R3
4.7 KΩ
4.7 KΩ
54
Encoder Power
OUT A
OUT Ã
OUT O
OUT Õ
Encoder Power Ground
OUT A
OUT Ã
R1
VCC
Encoder Power
R2
Encoder Power Ground
R3
R4
OUT Õ
OUT O
R4
6.2 KΩ
18 KΩ
Encoder
Signal
Encoder
Signal
