Parameter
AbnormalLineEnabl
e
PreampGain
DigitalShift (Enable)
BalanceWhiteAuto
BlackLevel
Camera Link Line Scan Camera
Command
r FrameTimeoutEnable
w AbnormalLineEnable 1
w PreampGain x
r PreampGain
w DigitalShift y or z
r DigitalShift
w BalanceWhiteAuto
r BalanceWhiteAuto
w BlackLevel x
User Manual
·
Value
1—enable
0—disable
1—enable
X:
Gain multiple value x
1000
x: the value you want
to set
y: write serial port
value and disable
digital shift
z: write serial port
value and enable
digital shift
y=x × 511 /6 +511
z=x × 511/6+66047
When value is larger
than 65536, digital
shift is enabled.
0—off
1—continue
2—once
0—off
1—continue
2—once
x: 0-4095
96
Description
FrameTimeoutEnable 0.
Read frame timeout
enable.
Enable abnormal line
function.
Set gain value.
E.g., w PreampGain 2700
(set the gain as 2.7 x)
Read gain value.
Set digital shift (enable).
Note: the range of digital
shift is -6 to 6.
E.g., w DigitalShift 512. It
means setting gain as
0.01, and disabling digital
shift.
E.g., w DigitalShift 66048.
It means setting gain as
0.01, and enabling digital
shift.
Read digital shift.
If digital shift is enabled,
read z and x =(z-66047) ×
6/511.
If digital shift is disabled,
read y, and x=y × 6/511-6.
Set white balance mode.
Eg: w BalanceWhiteAuto
2.
Read white balance mode.
Set black level. E.g., w
BlackLevel 5.
