Parameter
Counter Reset Source Read and write
Counter Reset
Counter Value
Counter Current
Value
If Timer Active is selected as Line Source, you can set Strobe Line Duration and Strobe Line Delay,
and the camera will output signal correspondingly after click Execute in Line Trigger Software.
If you need to let the camera output signals when it outputs one frame image, follow steps below
to set it.
Steps:
1. Click Digital IO Control, and select Frame Mode as Strobe Source Selector.
2. Set Line Source according to actual demands.
3. Enable Strobe Enable.
Camera Link Line Scan Camera
Read/Write
Write is available
under certain
condition
Read and write
Read only
Figure 8-4 Set Timer Active
User Manual
·
Description
It selects the signal source of resetting counter.
Software is available only. It is disabled by default.
It resets counter and it can be executed when
selecting Software as Counter Reset Source.
It is the counter value with the range of 1 to 1023.
It displays the number of executed external trigger.
