HikRobot MV-CL042-91CM User Manual page 100

Parameter
Reverse X
Direction Source
Reverse Scan
Direction
PixelFormat
PixelSize
Test Pattern
Camera Link Line Scan Camera
Command
r OffsetY
w ReverseX x
r ReverseX
w DirectionSource x
r DirectionSource
w ReverseScanDirection
x
r ReverseScanDirection
w PixelFormat x
r PixelFormat
r PixelSize
w TestPattern x
User Manual
·
Value
x:
0—disable
1—enable
x:
0—Internal (internal
control)
1—CC 3 (external
control)
x:
0—forward direction
1—reverse direction
x:
0x1080001--momo8
0x1100003--mono10
0x1100005--mono12
0x02180014--RGB 8
x：
0—off
14—ObliqueMonoBar
91
Description
Read vertical offset from
the origin to the region of
interest (in pixels).
Set image reverse X.
E.g., w ReverseX 1.
Read image reverse X.
Set control source of scan
direction. E.g., w
DirectionSource 1.
Set scan direction (internal
control). E.g., w
ReverseScanDirection 1.
Read scan direction.
Set pixel format. E.g., w
PixelFormat 0x1080001.
Read pixel format.
Note: the returned value
is decimal system and it
needs to be converted to
hexadecimal.
Read pixel size.
Set test pattern. E.g., w
TestPattern 14.
