FMC connector pin assignment
Signal Name
FMC_GBTCLK0_M2C_P
FMC_GBTCLK0_M2C_N
FMC_GBTCLK1_M2C_P
FMC_GBTCLK1_M2C_N
FMC_DP0_C2M_P
FMC_DP0_C2M_N
FMC_DP1_C2M_P
FMC_DP1_C2M_N
FMC_DP2_C2M_P
53 / 66
ZYNQ Ultrascale + FPGA Board AXU9EG User Manual
Figure 3-12-1: FMC Schematic
ZYNQ Pin Name
ZYNQ Pin
130_CLK0_P
130_CLK0_N
129_CLK0_P
129_CLK0_N
130_TX0_P
130_TX0_N
130_TX1_P
130_TX1_N
130_TX2_P
Amazon Store: https://www.amazon.com/alinx
Number
FMC Transceiver Reference Clock 0
G27
Positive
FMC Transceiver Reference Clock 0
G28
Negative
FMC Transceiver Reference Clock 1
L27
Positive
FMC Transceiver Reference Clock 1
L28
Negative
FMC Transceiver Data Transmission 0
F29
Positive
FMC Transceiver Data Transmission 0
F30
Negative
FMC Transceiver Data Transmission 1
D29
Positive
FMC Transceiver Data Transmission 1
D30
Negative
FMC Transceiver Data Transmission 2
B29
Positive
Description
