93
128_TX3_N
95
128_TX3_P
97
GND
99
128_TX2_N
101
128_TX2_P
103
GND
105
128_TX0_N
107
128_TX0_P
109
GND
111
128_TX1_N
113
128_TX1_P
115
GND
117
128_CLK0_N
119
128_CLK0_P
38 / 66
ZYNQ Ultrascale + FPGA Board AXU9EG User Manual
M30
M29
-
P30
P29
-
T30
T29
-
R32
R31
-
R28
R27
Amazon Store: https://www.amazon.com/alinx
94
128_RX3_N
96
128_RX3_P
98
GND
100
128_RX1_P
102
128_RX1_N
104
GND
106
128_RX0_P
108
128_RX0_N
110
GND
112
128_RX2_P
114
128_RX2_N
116
GND
118
128_CLK1_P
120
128_CLK1_N
M34
M33
-
P33
P34
-
T33
T34
-
N31
N32
-
N27
N28
