Maintenance manual
GMK5200-1
The used proportion S
is therefore:
0.5
×
S -------------- - 480 h
=
i
0.125
Remaining theoretical service life:
D2 = 3,040 h –1,920 h = 1,120 h.
The above values are entered in the table (see table example p. 5 - 28).
rd rd
3 inspection (3 year)
The truck crane was used for assembly work and occasional unloading work
on docks: Load spectrum: L 2, i.e. Km
The operating hours counter for the main hoist reads 940 h, i.e. during this
period: 940 h - 640 h = 300 h. T3 = 300 h.
The used proportion S
therefore:
0.25
×
S -------------- - 300 h
=
i
0.125
Remaining theoretical service life:
D3 = 1,120 h - 600 h = 520 h.
The values are entered in the table (see table example p. 5 - 28).
The remaining theoretical service life is to be documented in a separate
table for each winch.
This table is to be attached to the crane logbook. This table is to be found in
the maintenance manual's appendix for truck cranes that do not require a
crane logbook or similar documentation according to the regulations of the
respective country.
5.4 Measures required for winch monitoring
of theoretical service life after the second inspection
2
1,920 h
=
= 0.25.
3
of theoretical service life after the third inspection is
3
600 h
=
3 302 746 en
Maintenance overview
s
5 - 27
