Spare parts required for maintenance
11.2 Lighting
Installation point
SUPERSTRUCTURE LIGHTING:
Yellow marker lights:
(left and right on the main boom head)
– Marker light; complete
Red rear marker lights:
(on the turntable)
– Marker light; complete
Yellow rotating beacon:
(on the turntable)
– Rotating beacon; complete
Inside light:
(in the crane cab)
– Cab light
– Reading light
Spotlight, angular-shaped, permanently installed:
(at the front of the crane cab)
– Filament lamp
Spotlight, electrically adjustable:
(at the front of the main boom)
– Halogen bulb
11 - 4
GROVE part
number
03329569
03329492
04156048
01207144
00439055
01573349
03142726
3 302 746 en
Designation Power (W)
LED
LED
R10W
P25-1
H3 24V
8GS009028001
Maintenance manual
10
21
70
35
GMK5200-1
