H
Maintenance manual
GMK5200-1
1 RCL terminal box
2 Telescopic slide faces
3 Pressure sensors on the derricking cylinder
4 Lowering limit switch
5 Suspension struts
6 Heating/air conditioning system under the crane cab
7 Slewing angle sensor
8 Control units for outriggers
9 Angle data transmitter
10 RCL length data transmitter
11 Battery compartment
12 Spotlights, pivoting
13 RCL connections
14 Lifting limit switch
Assemblies at risk of damage on the lattice extension;
tions Lattice Extension .
3.1 Overview of assemblies easily damaged when cleaning
3 302 746 en
Cleaning
à
Operating Instruc-
3 - 3
