Maintenance work on the carrier
7.9 Axle lines
Prerequisites
O
nd th
2 and 5 axle
lines
rd
3 axle line
7 - 64
– The truck crane must be raised on outriggers or parked over an inspection
pit.
– The engine must be switched off and secured against unauthorised use;
à
p. 2 - 3.
Risk of environmental damage due to leaking consumables.
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that have leaked.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
This axle centre drive is available only with the 10 x 8 x 10 drive and is
flanged directly to the transfer case;
•
Place a receptacle under the screw (2).
•
Unscrew the screws (1) and (2) and allow the
oil to drain off.
•
Fit a new gasket and tighten the drain
screw (2).
•
Fill the oil up to the lower edge of the open-
ing.
•
Fit a new gasket and tighten the drain
screw (1).
à
Transfer case , p. 7 - 49.
•
Place a receptacle under the screw (2).
•
Unscrew the screws (1) and (2) and allow the
oil to drain off.
•
Fit a new gasket and tighten the drain
screw (2).
•
Fill the oil up to the lower edge of the open-
ing.
•
Fit a new gasket and tighten the drain
screw (1).
