Creating the fabric zones for CASA B

This section describes the fabric zones and port connections for CASA B.
Fabric CAM_C has CASW3 and CBSW4 and the following zones:
Fabric CAM_D has CASW4 and CBSW3 and the following zones:
92
Zone 1: port connections for H1_2 and CAP1T0
Zone 2: port connections for H1_2 and CAP1T1
Zone 3: port connections for H1_2 and CAP1T2
Zone 4: port connections for H1_2 and CAP1T3
Zone 5: port connections for H1_2 and CAP1T4
Zone 6: port connections for S2A2 and CBP1I1
Zone 7: port connections for S2B1 and CBP1I1
Zone 8: port connections for S2A2 and CBP0I4
Zone 9: port connections for S2B1 and CBP0I4
Zone 10: port connections between sites using CAP1T5 and CBP1I5
Zone 1: port connections for H2_2 and CBP1T0
Zone 2: port connections for H2_2 and CBP1T1
Zone 3: port connections for H2_2 and CBP1T2
Zone 4: port connections for H2_2 and CBP1T3
Zone 5: port connections for H2_2 and CBP1T4
Zone 6: port connections for S1B1 and CAP1I1
Zone 7: port connections for S1A2 and CAP1I1
Zone 8: port connections for S1B1 and CAP0I4
Zone 9: port connections for S1A2 and CAP0I4
Zone 10: port connections between sites using CAP1I5 and CBP1T5
