Connecting two appliances through a WAN
Figure 20
configuration includes the optional IP mirroring functionality.
In this example, assume the following:
Figure 20: Two appliances connected through a WAN
Continuous Access Storage Appliance Installation and Maintenance Guide
shows two appliances connected through a wide area network (WAN). This
Each peer node on the local and remote appliances connects to a Gigabit Ethernet router
(or switch), that connects to the WAN.
The host and storage array connections described on page 84 also apply to this example.
Connecting the Appliance to Hosts and Storage Arrays
87
