Installation and
Maintenance Guide
HP OpenView
Continuous Access Storage Appliance
Product Version: 5.7
Fourth Edition (May 2004)
Part Number: AA–RTD6D–TE
This guide describes how to install, configure, and maintain the HP OpenView Continuous Access Storage
Appliance (CASA), which uses two ProLiant servers.
