Creating a LUN

After the peer node detects the shared storage array, create LUN 0 using the entire space on the
array. Use the CommandView software or Hyper Terminal to create the LUN.

Using CommandView

To use CommandView to create LUN 0, you must first access the CommandView software.
Note:

Accessing CommandView

To access CommandView:
1. Ensure the hp OV CASA Console window is open in administrative mode.
2. Click switchui to open the Windows NT desktop. See
3. Click Start > Settings > Control Panel.
4. Double-click Network.
5. Double-click Protocol.
6. Select TCP/IP and click Properties.
7. Click Advanced.
8. Click Configure in the Enable security box.
9. Under TCP and UDP, select the Permit All options.
10. Exit all windows and reboot the appliance node when prompted.
11. Continue with
Continuous Access Storage Appliance Installation and Maintenance Guide
Complete this procedure on the peer node used in
instructions.
The Control Panel window opens.
The Network window opens.
The Protocol window opens.
The Properties dialog box opens.
The Advanced dialog box opens.
"Creating LUN 0 using
Replacing and Configuring Appliance Components
"Detecting the
"Using switchui" on page 28 for
CommandView."
array."
103
