Appliance Components
HP ProLiant ML370G3 server
Each appliance uses two servers, also called nodes. Each node is an HP ProLiant ML370G3
server; the appliance software is installed before it ships.
The nodes are defined as peer nodes in an active-active configuration, which means that both
nodes actively monitor and maintain the storage network.
For more information on this server, refer to the ProLiant ML370 Generation 3 Server Setup
and Installation Guide. This guide is available from the following HP web site:
http://wwss1pro.compaq.com/support/reference_library/viewdocument.asp?countrycode=1000&
prodid=5479&source=281992-001.xml&dt=262&docid=16266
Technical specifications
Processor
Hard drives
Memory
Cache memory
Network controller
Storage controller
System dimensions
Weight
Power supply
Operating temperature
Storage temperature
Relative humidity
(non-condensing)
138
Type
Intel Xeon 2.80 GHz processor
Six one-inch hot pluggable hard drive bays
1 GB Advanced ECC PC2100 DDR SDRAM running at
200 MHz
512 KB second-level ECC cache
NC7781 PCI-X Gigabit NIC (embedded) 10/100/1000
WOL (Wake on LAN)
Integrated dual channel wide Ultra3 SCSI adapter
8.69 x 19.0 x 25.75 inches
22.07 x 48.26 x 65.43 cm
65 pounds/29.48 kg (without hard drives, no RPS)
500 Watt-CE Mark hot plug
+5º C to +35º C (41º F to 95º F)
–40º C to +85º C (–40º F to 185º F)
5% to 95%
Continuous Access Storage Appliance Installation and Maintenance Guide
