Unpacking the Appliance

Identifying the node components

Figure 1
18
lists the node components, including the location of the initiator and target ports:
Dual–port Gigabit Ethernet card (1)
— Port A—MirrorLink
— Port B—InterLink
Four–port HBA card (2)
— Port 0—Target 2
— Port 1—Target 3
— Port 2—Initiator 2
— Port 3—Initiator 3
Four–port HBA card (3)
— Port 0—Target 4
— Port 1—Target 5
— Port 2—Initiator 4
— Port 3—Initiator 5
Four–port HBA card (4)
— Port 0—Target 0
— Port 1—Target 1
— Port 2—Initiator 0 (shared disk connection)
— Port 3—Initiator 1
USB connectors (5)
Unit ID switch and LED (6)
Auxiliary VHDCI SCSI blank (7)
Serial connector A (8)
Mouse connector (9)
Keyboard connector (10)
Serial connector B (11)
Primary hot-pluggable power supply (12)
Video connector (13)
Parallel connector (14)
iLO management port (15)
Ethernet 10/100/1000 port (16)
VHDCI SCSI port 2 connector (17)
Redundant hot-pluggable power supply (18)
